Cashew nut shelling processing line

General

Cashew nut processing plant is a whole line for shelling cashew nuts and roasting cashew kernels. Fully-automatic cashew nut shelling and cashew kernel peeling machines save lots labors.
Cashew nuts processing line procedures
1.) Cashew Nut Grading
2.) Cashew Nut Cooking
3.) Cashew Nut Shelling
4.) Cashew Kernel Separating
5.) Cashew Kernel Peeling
6.) Cashew Kernel Roasting

Cashew Nut Processing line machines

1. Cashew Nuts Auto Grading

Cashew nut grading machine can classify raw cashew nuts into several levels on basis of size and dimension. Generally cashew nut grading machine has three or four grades.

2. Steam Cooking

Raw cashew nuts in shell are steamed under pressure to soften the shells. The shell of cashew nut is very hard and it contains harmful oil ingredient. Cooked cashew nuts are easy to be cracked and shelled. The process of steam cooking helps in shelling cashew nuts with minimal effort.

3. Cashew Nut Cracking & Shelling

Cooked cashew nuts are cracked in automatic cashew nut shelling machines. A roller bearing is used to adjust the distance between rollers for cashew nuts in different size. The capacity of cashew nut shelling machine can reach 40 kg/h, and for cashew nut shelling line in 300 kg/h, we equip 7 shelling machines here.

4. Cashew shell & Kernel Separating

Cashew kernel separating shaker is used to separate cashew kernels from cashew shells and unshelled cashew nuts. After through cashew nut shelling machine, cashew shell pieces and kernels are separated by cashew shaker, and unshelled cashew nuts are returned to be re-shelled.

5. Cashew Peeling Machine

The red skin of each cashew kernel is removed by cashew kernel peeling machine for deep-processing products. This automatic cashew kernel peeling machine works with a air compressor and the internal parts of peeling machine are made from high quality stainless steel.

6. Cashew Kernel Roasting (Optional)

Roasted cashew kernels have a beautiful appearance and good flavor. Cashew roaster is fully automatic and high efficient. In the roasting process, cashew kernels are heated evenly in high temperature and they would not stick on the inner wall.

300kg/h cashew nut processing line specifications

Model Capacity No. Power Weight Dimension Cashew Nut Grading  Machine 400 kg/h 1 1.1KW/440V 1000 kg 3.7*0.85*1.6m Cashew Nut Steaming Machine 200 kg/h 2 440V/50HZ 300 kg 1.4*0.6*1.6m Cashew Nut Shelling  Machine 40 kg/h 7 1.1KW/440V 350 kg 1.36*0.8*1.75m Cashew Kernel  Separating Shaker 300 kg/h 1 1.1KW/440V 120 kg 1.95*0.83*1.15m Cashew Kernel Peeling Machine 300 kg/h 1 0.2KW/440V 110 kg 1* 0.75*1.5m Air Compressor / 1 15KW /440V 300 kg 1.65*0.7*1.3m Cashew Kernel Roasting Machine 300 kg/h 1 1.1KW/ 440V 460 kg 1.6*1.02*1.47
