High Shear Emulsifier (Pneumatic Lifting)

General

High-shear Emulsifier (Pneumatic Lifting) is a batch type machine designed for small volume in industrial production. Its working capacity is generally between 20-1000L. It narrows the particle size of liquid-liquid and liquid-solid materials through external mechanical force and distribute one phase materials into another phase or many other phases evenly to realize good homogenizing, dispersing and emulsifying result and obtain stable emulsion. High shear dispersing emulsifiers is a batch type machine. The working head is a new type with dual direction suction structure. The equipment can adapt to wide range viscosity and temperature, and can also customize to be ex-proof type.

[Materials Viscosity] :    ≤5000 cps

[Production Capacity] :  50-1000L

[Application Industry] : Suitable for dispersing, emulsifying and homogenizing material in industries such as biology, pharmacy, food , ink, textile auxiliary, cosmetic lubrication oil and fertilizer etc.. (For more application industry, Please click “Free Consultation”)

[Application Materials] :  Applicable for production process for solution, gel. Suspension or emulsionof solid – liquid, liquid – liquid materials such as juice, soup bases, milk Production, tissue homogenate, cosmetics, surfactants, asphalt, emulsifier, oil field chemicals etc.

Product Advantage

High efficiency, high product quality

With linear velocity more than 20m/s, it can distribute one phase materials into another phase or may other phase evenly in a short period to obtain fine homogenizing, dispersing emulsifying result. Its finished products are with stable quality and not easy to be laminated.

High precision processing and long service life

The Stator and rotor are forging materials processed in CNC machining center. The clearance between the state and rotor is very small to get good shearing result, high emulsifying and dispersing efficiency. And the stator and rotor also can be coated with Nano materials to extend their service life.

Safe and easy operation

Adopt air cylinder as lifting actuator. With pneumatic control valve to control emulsifier up, stop and down, low air consumption, easy to operate. The emulsifying head is fixed to the main shaft with hexagon socket-head cap screws,which can be disassembled and exchanged quickly, easy to cleanwith manual simple clamping to fix the tanks properly to present from accident due to the tank displacement during operation.

Easy to move

The equipment take up little space, with brake wheels to remove easily.

Technical Parameter

Model	Power (kw)	Speed (rpm)	Linear velocity (m/s)	Materials	Capacity (L)	Lifting (MM)
PVG-SRHQ-1.1	1.1	0-2930	21	SS304/SS316L	50	600
PVG-SRHQ-2.2	2.2	0-2930	21	SS304/SS316L	150	700
PVG-SRHQ-4	4	0-2930	20	SS304/SS316L	400	900
PVG-SRHQ-7.5	7.5	0-2930	20	SS304/SS316L	800	1100
PVG-SRHQ-11	11	0-2930	25	SS304/SS316L	1000	1100
